Delran Series 60mm Aluminum Windows
for Residential Applications

Upgrade your home with Vetrina's DELRAN aluminum windows, featuring a sleek 2 3/8” (60mm) frame, superior insulation with 1” polyamide rods, and moisture-tight EPDM gaskets. Fully customizable and available in tilt-and-turn, casement, hinged, fixed, and specialty styles to match your home's unique needs.

DELRAN INDUSTRIAL

Ideally suited for residential applications with both straight and curved sashes. Optional concealed hinges and advanced security hardware. A specially designed drainage system provides excellent performance against rain and dust.

PERFORMANCE & SPECS:

AAMA Rating @ 59” x 99”: AW-PG55
AAMA Rating (reinforced): AW-PG90
Design Pressure: 55.14 psf
Design Pressure (reinforced): 90.23 psf
Air Infiltration @ 6.24 psf: 0.06 cfm/ft²
Air Exfiltration @ 1.57 psf: <0.01 cfm/ft²
Water Resistance: 15.04 psf
Uniform Load @ 82.71 psf: <0.01”
Forced Entry: Type B - Grade 10
U-Value: 0.30 | STC: 48 dB
Maximum Glazing Thickness: 1-13/16”
Profile Thickness: 1/16” (1.6mm)

MAXIMUM DIMENSIONS PER SASH:
Subject to windows typology

Width (L): 59" (1,500mm)
Height (H): 102" (2,600mm)

SECTIONS:

FRAME: 2 3⁄8" (60mm)
SASH: 2 5⁄8" (68mm)

MAXIMUM WEIGHT PER SASH:
Subject to windows typology

352.74 lb (160kg)

OPENING OPTIONS:

Tilt & Turn
Turn Only (Side Hung)
Tilt Only (Hopper)
Fixed (Inoperable)

HARDWARE OPTIONS:

Concealed Hinges
Security Hardware

DOWNLOADS

Vetrina’s DELRAN window system is a great choice for residential applications because it offers a perfect balance of thermal efficiency, durability, and modern aesthetics.

Here’s why homeowners love it:

Excellent Thermal Performance: Its thermal break system and a U-value as low as 0.30 (depending on glazing) help improve energy efficiency and reduce heating and cooling costs.
Slim and Modern Design: The sleek 60mm frame allows for larger glass surfaces, maximizing natural light while maintaining a contemporary look.
Superior Weather Resistance: Its high-quality seals and EPDM gaskets provide strong protection against wind, rain, and air infiltration, ensuring comfort in any climate.
Versatile Opening Options: Available in tilt-and-turn, casement, fixed, and other configurations, making it adaptable to various home styles and needs.
Security & Durability: The robust aluminum frame, combined with multi-point locking systems, offers enhanced security while being low-maintenance and long-lasting.

DELRAN HIDDEN SASH

Our Delran Series with a hidden sash is a sleek, energy-efficient Euro-Groove window system with an impressive U-value of 0.30. Designed for modern homes, it offers superior protection against wind-driven rain, dust, and harsh weather—keeping your home comfortable and secure in any conditions.

PERFORMANCE & SPECS:

AAMA Rating @ 59” x 99”: AW-PG55
AAMA Rating (reinforced): AW-PG90
Design Pressure: 55.14 psf
Air Infiltration @ 6.24 psf: 0.06 cfm/ft²
Air Exfiltration @ 1.57 psf: <0.01 cfm/ft²
Water Resistance: 15.04 psf
Uniform Load @ 82.71 psf: <0.01”
Forced Entry (Type B): Grade 10
U-Value: 0.30 | STC: 45 dB
Max Glazing Thickness: 1 5/16” (34mm)
Profile Thickness: 1/16” (1.6mm)
Polyamide Strip Length: 1” (24mm)
